AT type oscillation suspensions bodies are made of sphero cast iron, their inner part are made of aluminum rod. The inner part connection can be made with bolt nut from two or one side. THE AT-type oscillation suspension is used to transmit the force from the crank arm to the system that will oscillate. The transmission of force from the crank arm to the system is made quiet and safe. The body attachment outer type is selected according to the external direction of the part to be connected.
Easy mounting
ESTA OSCILLATION
Long-lasting
ESTA OSCILLATION
AT type oscillation suspensions bodies are made of sphero cast iron, their inner part are made of aluminum rod. The inner part connection can be made with bolt nut from two or one side. THE AT-type oscillation suspension is used to transmit the force from the crank arm to the system that will oscillate. The transmission of force from the crank arm to the system is made quiet and safe. The body attachment outer type is selected according to the external direction of the part to be connected.
Easy mounting
ESTA OSCILLATION
Long-lasting
ESTA OSCILLATION
Model
Type | M
[ in N ] | α
max. | n err max in min¯¹ | A
| B | C
| D | E | F | G | H | I | J | K | Ağırlık
Weight
(Kg) |
AT 16
AT 16L | 300 | 10° | 1200 | 16 | 45 | Ø5 | 10 | 15 | 40 | 28 | 32,9 | 40 | 20 | M10
M10L | 0,25 |
AT 18
AT 18L | 420 | 10° | 1200 | 18 | 55 | Ø6 | 12 | 18,5 | 45 | 30,5 | 39,9 | 50 | 22 | M12
M12L | 0,41 |
AT 25
AT 25L | 1050 | 10° | 1200 | 25 | 65 | Ø8 | 18 | 23 | 60 | 44 | 49,9 | 60 | 28 | M 16
M 16L | 0,71 |
AT 35
AT 35L | 2100 | 10° | 800 | 35 | 90 | Ø10 | 23 | 31 | 80 | 55 | 65,9 | 80 | 42 | M 20
M 20L | 1,82 |
AT 45
AT 45L | 3600 | 10° | 800 | 45 | 110 | Ø12 | 35 | 41 | 100 | 67 | 87,8 | 100 | 48 | M 24
M 24L | 3,65 |
AT 50
AT 50L | 6200 | 10° | 600 | 50 | 130 | M12 | 40 | 45 | 105 | 70 | 95,8 | 120 | 60 | M 36
M 36L | 5,44 |
AT 60
AT 60L | 12050 | 6° | 400 | 60 | 210 | M12 | 45 | 56,5 | 130 | 87,5 | 113 | 200 | 80 | M 42
M 42L | 13,10 |
AT 60x300
AT 60x300L | 19000 | 6° | 400 | 60 | 310 | M16 | 45 | 56,5 | 130 | 87,5 | 113 | 300 | 90 | M 42
M 42L | 20,00 |
AT 80
AT 80L | 28600 | 6° | 400 | 80 | 310 | M20 | 60 | 75 | 160 | 102,5 | 150 | 300 | 103 | M 52
M 52L | 38,00 |
M = Yük kapasitesi N Montaj / M = Load capacity in N Per mount
Type AT installation
In order to reach maximum efficiency of the force of the eccentric lever action, the axis of the eccentric lever should go through the center of gravity of screen and be perpendicular to the fixation angle of the oscillating elements..
